SleeperFeatures

8Sleeper

HVAC

Intake

AllowsairtoentersleeperHVACunit.Donot

blockHVACairintake.

9Sleeper

HVACAir

IntakeFilter

Replaceable/cleanableltercleansairand

protectsheatexchangerfrombecoming

pluggedwithlintanddebris.

UpperBunk

GeneralInformation

Theoptionalupperbunkishingedandcanberaisedandlocked

outoftheway.Bracketsarelocatedoneachsidewalltohold

thebunkinthedownposition,andalatchislocatedonthe

passengersidetoholdthebunkorreleaseitfromitsstowed

position.Accesstotheupperbunkisprovidedbystepsthatare

attachedtothedriver-sidetowercabinet.

1.ReleaseLatch

2.UpperBunkFrame

3.UpperBunk

NOTE:Thesleepercompartmentisequippedwithadome

lighttoaidentryandexitintotheupperbunk.Thedome

lightOn/Offswitchesarelocatedontheinstrumentpanel

andonthesleepercontrolpanel.

120
