Navistar ProStar+ User Manual

InspectionGuide
RightFrontofTractor
1.SpringSuspension
2.ShockAbsorber
3.AirSuspension
4.WheelandLugNuts
5.Tire
6.Hub
7.SteeringLinkage
8.BrakeChamberHoses
9.SlackAdjuster
10.BrakeLiningandDrum
11.Frame
WARNING
Topreventpropertydamage,personalinjury,and
/ordeath,ifwheelsortiresmustbechanged,
obtainexperttireservicehelp.Mountingand
demountingoftiresshouldonlybeperformed
byqualiedpersonnelusingnecessarysafety
proceduresandequipment.
WARNING
Topreventpropertydamage,personalinjury,and
/ordeath,donotoperatevehicleifthereislossof
steeringorsuspension,whichcouldcauseloss
ofvehiclecontrol.
NOTE:Retreadtiresarenotrecommendedforuseon
steeringaxlesoftrucks.
1.SpringSuspension:Checkconditionofspringfor
cracks,breaks,orshifting.Inspectspringhanger
fasteners,shackles,U-bolts,andnutsforwear,damage,
andtightness.
2.ShockAbsorber:Checkforcracks,leaks,andmissing
orbrokenmountingboltsorbushings.
3.AirSuspension(ifequipped):Checkforairleaks,loose
components,anddamagetoairbag.Inspectstabilizer
barforworn,loose,ordamagedcomponents.
