SleeperFeatures

Cabinets/Storage

GeneralInformation

WARNING

Topreventpropertydamage,personalinjury,and

/ordeath,alwaysremovealllooseitemsfromthe

interiorandstoreappropriatelywhenvehicleisin

motion.Fallingitemscanbeadistractiontothe

driver,oraprojectilecancauseanaccident.

NOTE:Thefollowingwilldescribeandillustratethe

standardcabinetsandtheirstoragefunctionsforthe

International

ProStar

+Serieslongsleeper.Yourvehicle

maynothaveallofthesefeatures.

Thesleepercompartmentisdesignedtoaccommodate

severaldifferenttypesofcabinetcongurationstotall

needs.

1.OptionalDresserCabinetorOptionalRefrigeratorCabinet

2.AirlineCabinets

3.RearWardrobe

4.T owerWardrobe

123
