ModelDescription
ChassisSkirtInstallation
NOTE:Therearetwohooksonthebacksideofthechassis
skirtthatmustbefullyengagedonthemountingbartobe
securedproperly.
1.Graspbothendsofthechassisskirt,holdthebottom
ofthechassisskirtawayfromthevehicle,andslidethe
chassisskirtundertheedgeofthecab.
2.Lowerthebottomofthechassisskirtontothemounting
bar,alignthechassisskirtonthefrontchassisskirt,and
engagethetwohooks.
3.Rotatethelockinghandle90°upwardtolockthechassis
skirtinposition.
4.Securethelockinghandleinthekeeperbracket.
NOTE:IfvehicleisorderedwiththeoptionalNoIdle
Solution,therearpassengersidechassisskirtthatcovers
additionalbatterieswillremoveandinstallthesameasthe
reardriver-sidechassisskirt.
ExtendedChassisSkirts
OptionalextendedchassisskirtsareavailablefortheProStar
®
+
Seriestruckswithsleeperandfullaeropackage.While
thepassenger-sideextendedchassisskirtisstationary,the
driver-sideskirtopenstoallowaccesstothedeckladder.T o
open,pulloutontheupperrighthandcorneroftheextended
chassisskirtandopentoitsfullextension.T oclose,grabthe
upperrighthandcorneroftheextendedchassisskirtandguide
ittoitsfullyclosedposition.
25
