Oce 9600 - Page 263

Problem solving 263
▼
▼▼
▼
Clearing a tape jam
1
Open the front door of the reinforcement unit (see figure 160).
[160] Opening the reinforcement unit front door
2
Turn the two guide plates away from the pin roller and lock them into their
open position (see figure 161).
[161] Opening the guide plates
