123
Maintenance
7
Raise the wiper cleaning liquid bottle a little
and pull out the bottle after making sure that
all the liquid has owed into the printer.
Note
Visually check that the waste ink bottle is not full before
removing it.
8
Lift the wiper sponge little by little while
pulling it toward you. After conrming that
the liquid in the wiper sponge has completely
owed in the printer, remove the wiper
sponge.
To check the numbers of the nozzles
with nozzle map
If you can remove the wiper sponge from the wiper
unit, remove it and then go to step
9
.
If the wiper sponge adheres because ink has dried
and you cannot remove it, perform the following
steps
8-a
,
8-b
,
8-c
, and
8-d
before you continue to
step 9.
Required items
3. Gloves2. Sheet mount cleaning liquid1. Dropper
Note
The items 1, 2, and 3 above are included in the sheet mount cleaning kit A (IP6-261).
Do not discard the items 1 and 2 above after use, but use them again for sheet mount cleaning.
8-a
Draw 1 ml of sheet mount cleaning liquid
using the dropper.
Before printing Loading the media Adjustment
Maintenance
Advanced
operations
Troubleshooting Menu tree Appendix
To Next Page
