Oki IP-6620 - Page 167

To Next Page

To Previous Page

167

Advanced operations

Push

Open

Open the cover of the ink chip reader.

Insert the ink amount extension chip in the

ink chip reader.

Push

Close the cover of the ink chip reader.

READING...

PLEASE WAIT

The data of the ink amount extension chip is

read automatically.
