Troubleshooting

Close the front cover.

The carriage moves to the home position.

CARRIAGE IS MOVING

PLEASE WAIT

Load the media on the printer again.

See To load media on the Printer on page 48.

Note



When the printer is jammed with media, the print heads may contact the media and cause print misses. In such cases,

perform print head recovery. (

page 204

)
