CHAPTER 9 – Animation OMRON
Page 154 Release 2.0
To abort the Display Text Value edit, click the Cancel pushbutton. By clicking the Browse
pushbutton, a point may be directly specified, as described in chapter 9, Runtime Actions. Once
completed, click the OK pushbutton. If invalid data has been inserted into any field, a descriptive
error message is displayed.
Edit Point Value (Digital)
The value of a Boolean point may be issued to the user for amendment during runtime, defined using
the User Input (Digital) dialog.
To access the User Input (Digital) dialog to add an action, select Edit Point Value (Digital) from the
animation list and click the Add Action button on the toolbar. To access the User Input (Digital)
dialog to modify an action, select Edit Point Value (Digital) from the animation list and click the
Modify Action button on the toolbar. For a list of the objects to which this action is applicable refer
to chapter 9, Objects.
On selection of the Edit Point Value (Digital) action, the dialog is displayed:
A Boolean point must be entered. This is typed into the Boolean Point: field. A text string to use as
the caption of a user dialog can be entered in the Caption: field. The range of input for the value, and
the representations of Boolean State 0 and Boolean State 1 are specified in the State 0 Text: field and
State 1 Text: field. If In Place Edit is not checked a popup dialog performs the edit. If it is checked,
the option is edited on the page with the options in a dropdown listbox.
To abort the Edit Point Value (Digital) edit, click the Cancel pushbutton. By clicking the Browse
pushbutton, a point may be directly specified, as described in chapter 9, Runtime Actions. Once
completed, click the OK pushbutton. If invalid data has been inserted into any field, a descriptive
error message is displayed.
During runtime, selecting the user input object by clicking the left mouse button results in the digital
value being edit either with the runtime User Input (Digital) dialog being displayed or the in place
listbox, based on the contents of the development version.
