3-44
Function No. Name Description Setting
range
Refer-
ence
page
Electronic ther-
mal protection
function selec-
n032 Motor rated
current
Set rated input current of motor with 1-A
units as motor basic current for electronic
thermal protection.
See
note 1,
2
3-64
tion
n033 Electronic ther-
mal protection
function selec-
tion
0: No protection.
1: For standard motors with standard rat-
ings (with a time constant of 8 min).
2: For standard motors with short-time rat-
ings (with a time constant of 5 min).
3: For Inverter-dedicated motors with
standard ratings (with a time constant
of 8 min).
4: For Inverter-dedicated motors with
short-time ratings (with a time constant
of 5 min).
0 to 4
[1]
3-65
Overheating
stop mode
selection
n034 Selection of
stop method for
when radiation
fin overheats
0: Deceleration stop in deceleration time 1
set with n020
1: Free running stop
2: Deceleration stop in deceleration time 2
set with n022
3: Continuous operation with warning
0 to 3
[3]
3-65
Note 1. Default settings vary with the Inverter model.
Note 2. The motor’s rated current setting range is 10% to 200% of the Inverter’s rated current.
Preparing for Operation Chapter 3
