Omron SYSDRIVE 3G3HV SERIES User Manual

5-20
A
B
J
(Mounting
screw)
J (Mounting
screw)
E
G
E
G
D
F
F
D
F
H
H
F
C
A
B
C
42
210 210
42
Six, 9 dia.
60
405030
64
160
12.5
8
60
275
300
47
M12
M12
47
510
516
A
B
E
G
D
J (Mounting
screw)
F
H
C
External Figure 1 External Figure 2
External Figure 3 External Figure 4
Model
3G3IV
Figure
(b )
Dimensions (mm)
Weight
(k )
3G3IV-
g
(above)
A B C D E F G H J
g
(kg)
PFN258L4207
1
329 300 325 185 70 M6 45 314 4-M5 2.8
PFN258L5507 329 300 353 185 80 M6 55 314 4-M5 3.1
PFN258L7534
2
329 300 377 220 80 M6 55 314 4-M5 4
PFN258L10035 379 350 436 220 90 M10 65 364 4-M5 5.5
PFN258L13035 439 400 486 240 110 M10 80 414 4-M5 7.5
PFN258L18007 3 438 400 480 240 110 M10 80 413 4-M5 11
PFN359P25099
4
--- --- --- --- --- --- --- --- --- 16
PFN359P30099 --- --- --- --- --- --- --- --- --- 16
Specifications Chapter 5
