6-11
Function
Refer-
ence
page
Setting
range
DescriptionNameNo.
Sequential in-
put function
selection
n039 Multi-function
input 5 (S6)
0to 22: Same as n035
25: Up/Down command
S5 will be used for the up command,
S6 will be used for the down com-
mand, and value set with n038 will be
ignored.
26: Not used. (Do not set.)
27: PID input characteristic selection
(ON: Deviation multiplied by –1)
2 to 27
[10]
3-18
Sequential out-
put function
selection
n040 Multi-function
contact output
1 (MA-MB-MC)
0: Error (ON: Error)
1: Running
2: Frequency agreement
3: Optional frequency agreement
4: Optional frequency detection (ON:
Output frequency x n073)
5: Optional frequency detection (ON:
Output frequency x n073)
6: Overtorque (ON: Detected)
7: Overtorque (OFF: Detected)
8: Baseblock
9: Operation mode (ON: Digital Opera-
tor/Frequency reference)
10: Inverter ready
11: Timer function output (Set with n077
and n078)
12: Error retrying
13: Inverter/Motor overload warning
14: Frequency reference loss (ON: Fre-
quency reference has dropped by
90% or more within 0.4 s)
15: Not used
16: PID feedback loss (Detecting method
can be set with n093 and n094)
17: Heating heat sink (ON: OH1)
0 to 17
[0]
3-74
n041 Multi-function
contact output
2 (M1-M2)
Same as n040 0 to 17
[1]
3-74
Appendix Chapter 6
To Next Page
