H Group 3: n050 to n108
Function No. Name Description Setting
range
Refer-
ence
page
Carrier frequen-
cy adjustment
n050 Carrier fre-
quency
(See note 1)
1: 2.5 kHz
2: 5.0 kHz
3: 8.0 kHz
4: 10.0 kHz
5: 12.5 kHz
6: 15.0 kHz
7, 8, and 9: Varies in proportion to output
frequency up to 2.5 kHz.
10:7.0 kHz
1 to 10
See
note 2
3-80
Instantaneous
power failure
processing and
speed search
control
n051 Selection of
running after
restoration fol-
lowing a mo-
mentary stop
0: Inverter will discontinue running.
1: Inverter will continue running if power is
supplied again within instantaneous
power failure compensation time set
with n055.
2: Inverter will always continue running
without detecting UV1 or UV3.
0 to 2
[0]
3-81
n052 Speed search
control level
Set current level enabling speed search in
1% units based on rated output current of
Inverter as 100%.
0 to
200
[110]
3-82
n053 Minimum base-
block time
Set time to start speed search after RUN
input is ON and instantaneous power fail-
ure processing starts.
0.5 to
10.0
(See
note)
3-82
n054 V/f characteris-
tics during
speed search
Set percentage of V/f characteristics for
speed search.
0 to
100
(See
note)
3-82
n055 Stop com-
pensation time
Set instantaneous power failure com-
pensation time in 1-s units.
0.0 to
2.0
(See
note)
3-82
Error retry
n056 Number of er-
ror retries
Set number of error retries. 0 to 10
[0]
3-83
n057 Selection of er-
ror output dur-
ing error retry
0: Turns ON error output while error retry
is performed.
1: Turns OFF error output while error retry
is performed.
0, 1
[0]
3-83
Note 1. For
a 400-V Inverter
, if the carrier frequency is set to a value higher than the default setting, the
Inverter overload “OL2” detection value will decrease in consideration of an increase in the
heat that will be generated by the change in the carrier frequency.
Note 2. Default settings vary with the Inverter model.
