Oracle Exalogic Elastic Cloud User Manual

Table E-5 (Cont.) InfiniBand Network Cabling for Exalogic Machine Full Rack
From
Rack Unit
(Sun
Network
QDR
InfiniBand
Gateway
Switch)
Port To Rack
Unit
Type of
Equipment
Port Description
U26 12A U36 Compute node PCIe 2, P1 2 meter QDR
InfiniBand cable
U26 12B U35 Compute node PCIe 2, P2 2 meter QDR
InfiniBand cable
U26 13A U34 Compute node PCIe 2, P2 2 meter QDR
InfiniBand cable
U26 13B U33 Compute node PCIe 2, P2 2 meter QDR
InfiniBand cable
U26 14A U32 Compute node PCIe 2, P2 2 meter QDR
InfiniBand cable
U26 14B U31 Compute node PCIe 2, P2 2 meter QDR
InfiniBand cable
U26 15A U30 Compute node PCIe 2, P2 2 meter QDR
InfiniBand cable
U26 15B U29 Compute node PCIe 2, P2 2 meter QDR
InfiniBand cable
U24 9A U42 Compute node PCIe 2, P2 3 meter QDR
InfiniBand cable
U24 9B U41 Compute node PCIe 2, P2 3 meter QDR
InfiniBand cable
U24 10A U40 Compute node PCIe 2, P2 3 meter QDR
InfiniBand cable
U24 10B U39 Compute node PCIe 2, P2 3 meter QDR
InfiniBand cable
U24 11A U38 Compute node PCIe 2, P2 3 meter QDR
InfiniBand cable
U24 11B U37 Compute node PCIe 2, P2 2 meter QDR
InfiniBand cable
U24 12A U36 Compute node PCIe 2, P2 2 meter QDR
InfiniBand cable
U24 12B U35 Compute node PCIe 2, P1 2 meter QDR
InfiniBand cable
InfiniBand Network Cabling Tables
