Table E-5 (Cont.) InfiniBand Network Cabling for Exalogic Machine Full Rack
From
Rack Unit
(Sun
Network
QDR
InfiniBand
Gateway
Switch)
Port To Rack
Unit
Type of
Equipment
Port Description
U24 13A U34 Compute node PCIe 2, P1 2 meter QDR
InfiniBand cable
U24 13B U33 Compute node PCIe 2, P1 2 meter QDR
InfiniBand cable
U24 14A U32 Compute node PCIe 2, P1 2 meter QDR
InfiniBand cable
U24 14B U31 Compute node PCIe 2, P1 2 meter QDR
InfiniBand cable
U24 15A U30 Compute node PCIe 2, P1 2 meter QDR
InfiniBand cable
U24 15B U29 Compute node PCIe 2, P1 2 meter QDR
InfiniBand cable
U23 7A U28 Compute node PCIe 2, P1 2 meter QDR
InfiniBand cable
U23 7B U27 Compute node PCIe 2, P1 2 meter QDR
InfiniBand cable
U23 8A U22 Storage appliance
server head
PCIe 0, P2 2 meter QDR
InfiniBand cable
U23 8B U21 Storage appliance
server head
PCIe 0, P2 2 meter QDR
InfiniBand cable
U23 9A U15 Compute node PCIe 2, P1 2 meter QDR
InfiniBand cable
U23 9B U14 Compute node PCIe 2, P1 2 meter QDR
InfiniBand cable
U23 10A U13 Compute node PCIe 2, P1 2 meter QDR
InfiniBand cable
U23 10B U12 Compute node PCIe 2, P1 2 meter QDR
InfiniBand cable
U23 11A U11 Compute node PCIe 2, P1 3 meter QDR
InfiniBand cable
InfiniBand Network Cabling Tables
Cabling Tables E-9
