Table E-8 (Cont.) InfiniBand Network Cabling for Exalogic Machine Half Rack
From
Rack Unit
(Sun
Network
QDR
InfiniBand
Gateway
Switch)
Port To Rack
Unit
Type of
Equipment
Port Description
U23 7B U27 Compute node PCIe 2, P1 2 meter QDR
InfiniBand cable
U23 8A U22 Storage appliance
server head
PCIe 0, P2 2 meter QDR
InfiniBand cable
U23 8B U21 Storage appliance
server head
PCIe 0, P2 2 meter QDR
InfiniBand cable
U23 9A U15 Compute node PCIe 2, P1 2 meter QDR
InfiniBand cable
U23 9B U14 Compute node PCIe 2, P1 2 meter QDR
InfiniBand cable
U23 10A U13 Compute node PCIe 2, P1 2 meter QDR
InfiniBand cable
U23 10B U12 Compute node PCIe 2, P1 2 meter QDR
InfiniBand cable
U23 11A U11 Compute node PCIe 2, P1 3 meter QDR
InfiniBand cable
U23 11B U10 Compute node PCIe 2, P1 3 meter QDR
InfiniBand cable
U23 12A U9 Compute node PCIe 2, P2 3 meter QDR
InfiniBand cable
U23 12B U8 Compute node PCIe 2, P2 3 meter QDR
InfiniBand cable
U23 13A U7 Compute node PCIe 2, P2 3 meter QDR
InfiniBand cable
U23 13B U6 Compute node PCIe 2, P2 3 meter QDR
InfiniBand cable
U23 14A U5 Compute node PCIe 2, P2 3 meter QDR
InfiniBand cable
U23 14B U4 Compute node PCIe 2, P2 3 meter QDR
InfiniBand cable
U23 15A U3 Compute node PCIe 2, P2 3 meter QDR
InfiniBand cable
InfiniBand Network Cabling Tables
Cabling Tables E-15
