Oracle Exalogic Elastic Cloud User Manual

Table E-8 (Cont.) InfiniBand Network Cabling for Exalogic Machine Half Rack
From
Rack Unit
(Sun
Network
QDR
InfiniBand
Gateway
Switch)
Port To Rack
Unit
Type of
Equipment
Port Description
U23 15B U2 Compute node PCIe 2, P2 3 meter QDR
InfiniBand cable
U16 7A U28 Compute node PCIe 2, P2 3 meter QDR
InfiniBand cable
U16 7B U27 Compute node PCIe 2, P2 3 meter QDR
InfiniBand cable
U16 8A U22 Storage appliance
server head
PCIe 0, P1 3 meter QDR
InfiniBand cable
U16 8B U21 Storage appliance
server head
PCIe 0, P1 3 meter QDR
InfiniBand cable
U16 9A U15 Compute node PCIe 2, P2 2 meter QDR
InfiniBand cable
U16 9B U14 Compute node PCIe 2, P2 2 meter QDR
InfiniBand cable
U16 10A U13 Compute node PCIe 2, P2 2 meter QDR
InfiniBand cable
U16 10B U12 Compute node PCIe 2, P2 2 meter QDR
InfiniBand cable
U16 11A U11 Compute node PCIe 2, P2 2 meter QDR
InfiniBand cable
U16 11B U10 Compute node PCIe 2, P2 2 meter QDR
InfiniBand cable
U16 12A U9 Compute node PCIe 2, P1 2 meter QDR
InfiniBand cable
U16 12B U8 Compute node PCIe 2, P1 2 meter QDR
InfiniBand cable
U16 13A U7 Compute node PCIe 2, P1 2 meter QDR
InfiniBand cable
U16 13B U6 Compute node PCIe 2, P1 3 meter QDR
InfiniBand cable
InfiniBand Network Cabling Tables
E-16 Oracle Exalogic Elastic Cloud Machine Owner's Guide
