Automatic Operation (Positioning Control)
7-26
• Repeating E-point control (with dwell time: 0 ms)
When the positioning unit detects a deceleration stop, the positioning unit will come to a stop
after repeating positioning control N+2 times.
• Implementing a number of positioning tables continuously
When the positioning unit detects a deceleration stop, the positioning unit will come to a stop
after repeating positioning control N+1 times.
The example below is a case of single-axis control with the positioning unit installed in the slot
1. The movement amount setting uses an increment method in pulses.
