17.2 I/O Number Allocation
17-13
Contact
allocation
Target axis Name Description
WY6
Y60 1st axis
Error clear
request
Requests the error clear of the corresponding axis.
The processing to recover from errors is performed and the error logs are
cleared by turning ON this signal.
Note) Unrecoverable errors cannot be recovered even if this signal turns ON.
Y61 2nd axis
Y62 3rd axis
Y63 4th axis
Y64
|
Y66
− − −
Y67 Virtual axis
Error clear
request
Requests the error clear of the virtual axis.
Y68 1st axis
Request
warning clear
Requests the warning clear of the corresponding axis.
The warning logs are cleared by turning ON this signal.
Y69 2nd axis
Y6A 3rd axis
Y6B 4th axis
Y6C
|
Y6E
− − −
Y6F Virtual axis
Request
warning clear
Requests the warning clear of the virtual axis.
WY7
Y70
|
Y7F
− − −
WY8
Y80 1st axis
Synchronous
setting
request
This contact will turn ON after the synchronous operation settings are
changed.
The unit turns OFF this contact after the setting change.
Y81 2nd axis
Y82 3rd axis
Y83 4th axis
Y84
|
Y87
− − −
Y88 1st axis
Synchronous
cancel request
Turns ON the contact for the axis to cancel the synchronous operation.
The unit will not perform the synchronous operation of the axis for which
this contact is ON.
Y89 2nd axis
Y8A 3rd axis
Y8B 4th axis
Y8C
|
Y8F
－ － －
