60″ (S) model
FRONT
REAR
Shock Travel
1
6.72″ (17.07 cm) 7.52″ (19.10 cm)
Extended Length
2
22.52″ (57.20 cm) 22.47″ (57.07 cm)
IFP Depth
3
3.00″ (7.62 cm) 3.20″ (8.13 cm)
Nitrogen Pressure
100 PSI (690 kPa)
Gas Shock Oil 2874124 (qt)
Compression Adjustment (factory)
4
12 clicks CCW from full stop
Spring Adjustment Setting (factory)
5
7.39″ (18.77 cm) 2.80″ (7.11 cm)
60″ (S) Front Shock Valving
COMPRESSION REBOUND
1.600 x .008 DB 1.425 x .008
1.600 x .008 1.425 x .008
1.600 x .008 1.425 x .008
1.600 x .008 0.800 x .006
0.750 x .008 1.425 x .012
1.600 x .012 1.350 x .012
1.600 x .012 1.250 x .012
1.600 x .012 1.100 x .012
1.600 x .012 0.950 x .012
1.600 x .012 1.230 x .082 Top Out
1.600 x .012 0.750 x .100 Back Up
1.100 x .006
1.570 x .128 Top Out
60″ (S) Rear Shock Valving
COMPRESSION REBOUND
1.600 x .006 DB 1.425 x .010
1.600 x .010 1.425 x .010
1.600 x .010 1.425 x .008
1.600 x .010 0.950 x .006
1.050 x .006 1.425 x .020
1.600 x .015 1.425 x .020
1.600 x .015 1.425 x .020
1.425 x .015 1.425 x .020
1.425 x .015 1.250 x .015
1.350 x .015
1.230 x .082 Top Out
1.350 x .015
1.250 x .015
1.250 x .015
1.100 x .015
1.570 x .128 Top Out
