8.34
9925723 R01 - 2015 RZR 900 Service Manual
© Copyright 2014 Polaris Industries Inc.
42.Push needle out of shock shaft using a metering rod
and Hex T-handle wrench.
43.Remove O-ring from needle.
44.Back out rebound adjuster with flat head screw driver.
45.Keep a magnet close to catch ball and spring when
the round adjuster is almost out.
46.Remove dust boot.
47.Remove both retaining rings from the eyelet and
press out bearing.
STEERING / SUSPENSION
