8.35

9925723 R01 - 2015 RZR 900 Service Manual

For DX bushing and seal style eyelet, follow the removal

procedures below.

1. Remove both dust seals from the eyelet.

2. Press out DX bushing using DX Bushing Press Kit

(803-00-935).

NOTE: DX Bushing style eyelets have larger bore

diameters than conventional eyelets.

3. Remove dust seal from bearing cap.

NOTE: On some models the seal may be in the

bearing assembly.

4. Remove low friction seal pack from bearing

assembly.

5. Remove U-Cup seal from bearing assembly. Note the

direction seal was installed.

6. Remove external O-ring from bearing assembly.

NOTE: If internal bearing is damaged, replace

with complete bearing assembly.

STEERING / SUSPENSION
