Polaris 2015 RZR 900 Service Manual

3.26
9925723 R01 - 2015 RZR 900 Service Manual
© Copyright 2014 Polaris Industries Inc.
9. Remove the six exhaust head pipe fasteners
7
and
the two springs
8
retaining the pipe to the muffler.
10.Remove the four screws retaining the engine and
PVT intake vents.
11. Loosen the PVT intake clamp.
12.Remove the two bolts mounting the air box to the
frame bracket and loosen the clamp on the air box
duct. Remove the air box from vehicle.
13.Remove the 22 screws retaining the cargo box panel.
14.Remove the ignition coil by disconnecting the wiring
leads and removing the two mounting bolts. Remove
the spark plug caps.
15.Disconnect the following electrical components:
9
TMAP
10
Electronic Throttle Control
11
Taillight Harness
12
Engine Temp Sensor
13
Speed Sensor
14
CPS
15
Transmission Switch
16
Differential Relay (if equipped)
ENGINE / COOLING SYSTEM
