Polaris 2015 RZR 900 Service Manual

3.30
9925723 R01 - 2015 RZR 900 Service Manual
© Copyright 2014 Polaris Industries Inc.
11. Install the four fasteners retaining the intake manifold
to the engine
1
and the one to retain the bottom of
the intake manifold to the transmission bracket.
Intake Manifold Mounting Fasteners:
To Engine: 17 ft-lb (23 Nm)
Lower: 22 ft-lb (30 Nm)
12.Install the two fuel rail mounting fasteners. Torque
fasteners to specification.
Fuel Rail Mounting Fasteners
7 ft-lb (10 Nm)
13.Route the harness and install the three harness
clamps on the intake manifold
2
.
14.Install the three fasteners retaining the harness to the
intake manifold
3
and two fasteners retaining the
harness by the transmission
4
switch.
Harness Mounting Bracket Screws:
35 in-lb (4 Nm)
ENGINE / COOLING SYSTEM
