9928491 R04 - 2017-2018 RZR XP Turbo / XP4 Turbo Service Manual
© Copyright Polaris Industries Inc.
CIRCUIT PIN FUNCTION
26 Power In
29 Power Out
30 Coil Low
Unsw 10A Fuse
27 Power In
31 Power Out
Drive 10A Fuse
28 Power In
32 Power Out
Chassis Relay
33
Coil High
34 Power In
37 Power Out
38 Coil Low
Accy Relay
35
Coil High
36 Power In
39 Power Out
40 Coil Low
Term 10A Fuse
41 Power In
45 Power Out
Accy 10A Fuse
42 Power In
46 Power Out
Key 10A Fuse
43 Power In
47 Power Out
Insr 10A Fuse
44 Power In
48 Power Out
