Polycom HDX 7000 Series User Manual

Administrator’s Guide for Polycom HDX Systems
3–26 Polycom, Inc.
Detect Camera
Polycom HDX 9006
Polycom HDX 9004
Polycom HDX 9002
Polycom HDX 9001
Polycom HDX 8000 HD
Polycom HDX 7000 HD
Polycom HDX 7000
Polycom HDX 6000 HD
Detects any supported PTZ camera connected to
Polycom HDX system video input 1 and configures the
camera settings accordingly.
Note: If a camera fails to wake up when the HDX
system wakes up, try detecting the camera again.
Camera 2
Polycom HDX 9006
Polycom HDX 9004
Polycom HDX 9002
Polycom HDX 9001
Polycom HDX 8000 HD
Specifies the camera’s aspect ratio:
•4:3 — Select if you are using a regular camera.
•16:9 — Select if you are using a wide-screen
camera.
This setting also configures the following SD cameras to
produce the corresponding video format:
• Polycom PowerCam Plus
• Polycom PowerCam
• Sony EVI-D100
• Sony BRC-300
Specifies the camera’s format. For a list of available
formats, refer to the information for your system in the
previous section of this chapter, Connecting Cameras
on page 3-15.
Name
Polycom HDX 9006
Polycom HDX 9004
Polycom HDX 9002
Polycom HDX 9001
Polycom HDX 8000 HD
Specifies a name and icon for the camera.
Note: If your HDX system is paired with a Polycom
Touch Control and you change a camera icon on the
HDX system, the Touch Control continues to show the
default icon.
Source
Polycom HDX 9006
Polycom HDX 9004
Polycom HDX 9002
Polycom HDX 9001
Specifies whether the camera source is People or
Content. Video sources specified as Content are sent
at a higher resolution and lower frame rate.
Content sent to Polycom HDX 8000 systems displays at
a maximum of 720p.
Video Quality
Polycom HDX 9006
Polycom HDX 9004
Polycom HDX 9002
Polycom HDX 9001
Polycom HDX 8000 HD
Specifies Motion or Sharpness for the video input.
•Motion — This setting is for showing people or
other video with motion.
•Sharpness — The picture will be sharp and clear,
but moderate to heavy motion at low call rates can
cause some frames to be dropped. Sharpness is
available in point-to-point H.263 and H.264 calls
only.
Setting Description
Artisan Technology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www.artisantg.com

Polycom HDX 7000 Series Specifications

General

Content Sharing	H.239, People+Content
Microphone	Polycom HDX Microphone Array
Network Protocols	H.323, SIP
Data Standards	H.239
Video Outputs	2 x DVI-I
Operating Temperature	0°C to 40°C (32°F to 104°F)
Video Standards	H.264, H.263, H.261
Video Resolution	Up to 1920 x 1080
Audio Standards	G.711, G.722.1, G.729A
Camera	Polycom EagleEye Camera
Connectivity	Ethernet, ISDN
Video Inputs	DVI-I
Audio Inputs	RCA
Audio Outputs	RCA
Network Interfaces	10/100/1000 Ethernet
Power Supply	100-240V AC, 50/60Hz
