Polycom HDX 8000 Series Systems
The following table shows how you can connect video sources to a Polycom
HDX 8000 series system.
3 (VCR/DVD Player)
BNC
Component
(Component
is Polycom
HDX 9004
only)
People or Content:
720p/60, 720p/50, 480p/60,
480p/30, 576p/50, 576p/25,
480i/60, 576i/50
People Only:
1080p/30, 1080i/60,
1080p/25, 1080i/50
Audio Input 3 None None
(Use
Serial
Port)
Composite,
S-Video
People or Content:
480i/60, 576i/50
Audio Input 3 None None
(Use
Serial
Port)
4 DVI-I DVI-A,
DVI-D
People or Content:
640 x 480/60, 800 x 600/60,
1024 x 768/60, 1280 x
720/60, 1280 x 1024/60
Audio Input 4
(Polycom
HDX 9004)
None None
(Use
Serial
Port)
5
Polycom
HDX 900
4
DVI-I DVI-A,
DVI-D
People or Content:
640 x 480/60, 800 x 600/60,
1024 x 768/60, 1280 x
720/60, 1280 x 1024/60
None None None
(Use
Serial
Port)
Video
Input
Number Connector
Acceptable
Input
Resolution/
Frame Rate (fps)
Audio
Association Power Control
Video
Input
Number Connector
Acceptable
Input
Resolution/
Frame Rate (fps)
Audio
Association Power Control
1 HDCI Composite,
S-Video
People Only:
480i/60, 576i/50
None Provided
for
EagleEye
cameras
PTZ
Camera,
IR Input
Component People Only:
720p/60, 720p/50,
480p/60, 480p/30,
576p/50, 576p/25,
480i/60, 576i/50
1080p/30, 1080i/60,
1080p/25, 1080i/50
None Provided
for
EagleEye
cameras
PTZ
Camera,
IR Input
