Polycom HDX 7000 Series

Administrator’s Guide for Polycom HDX Systems
A–8 Polycom, Inc.
Polycom HDX 7000 Series System (Hardware Versions A, B, C)
Polycom HDX 7000 System with Hardware Version D
Polycom Microphone
Input
Audio Input AUX:
RCA for line input
Audio Output 1: RCA for
main monitor audio or
external speaker system
Audio Input 2: RCA for
VCR/DVD player audio
Audio Output 3: RCA for
VCR/DVD player audio
Audio Input 3: 3.5 mm for
content audio
3
3
VCR/DVD
2
VCR/DVD
2
AUX
Polycom Microphone
Input
Audio Input AUX:
RCA for line input
Audio Output 1: RCA for
main monitor audio or
external speaker system
Audio Input 2: RCA for
VCR/DVD player audio
Audio Input 3: 3.5 mm for
content audio
