Polycom HDX 7000 Series

System Back Panel Views
Polycom, Inc. A–7
Polycom HDX 9001 and Polycom HDX 9002
Polycom HDX 8000 Series System
Audio Input 1: Phoenix for
microphone or line input
Audio Output 1: Phoenix for main
monitor audio or external
speaker system
Audio Output 3: Phoenix for
VCR/DVD player audio
Polycom Microphone
Inputs
Audio Input 3: Phoenix for
VCR/DVD player audio
Polycom Microphone
Inputs
Audio Input 1: RCA for
line input
Audio Output 1: RCA for
main monitor audio or
external speaker system
Audio Input 3: RCA for
VCR/DVD player audio
Audio Output 3: RCA for
VCR/DVD player audio
Audio Input 4: 3.5 mm for
content audio
