Polycom HDX 7000 Series User Manual

Administrator’s Guide for Polycom HDX Systems
3–22 Polycom, Inc.
Polycom HDX 7000 Series Systems
The following table shows how you can connect video sources to a Polycom
HDX 7000 Hardware Version A, B, C, or D system.
2 HDCI Composite,
S-Video
People or Content:
480i/60, 576i/50
None None PTZ
Camera
Component People or Content:
720p/60, 720p/50,
480p/60, 480p/30,
576p/50, 576p/25,
480i/60, 576i/50
People Only:
1080p/30, 1080i/60,
1080p/25, 1080i/50
None None PTZ
Camera
3
(VCR/DVD
Player)
S-Video Composite,
S-Video
People or Content:
480i/60, 576i/50
Audio Input 3 None None
(Use
Serial
Port)
4 DVI-I DVI-A, DVI-D People or Content:
640 x 480/60, 800 x
600/60, 1024 x 768/60,
1280 x 720/60, 1280 x
960/60, 1280 x
1024/60, 1680 x
1050/60, 1920 x
1080/60
Audio Input 4 None None
(Use
Serial
Port)
Video
Input
Number Connector
Acceptable
Input
Resolution/
Frame Rate (fps)
Audio
Association Power Control
Video
Input
Number Connector
Acceptable
Input
Resolution/
Frame Rate (fps)
Audio
Association Power Control
1 HDCI Composite,
S-Video
People Only:
480i/60, 576i/50
None Provided
for
EagleEye
cameras
PTZ
Camera,
IR Input
Component People Only:
720p/60, 720p/50, 480p/60,
480p/30, 576p/50, 576p/25,
480i/60, 576i/50, 1080p/30,
1080i/60, 1080p/25,
1080i/50
None Provided
for
EagleEye
cameras
PTZ
Camera,
IR Input
