Administrator’s Guide for Polycom HDX Systems
11–6 Polycom, Inc.
Video (Monitors)
Video Cameras
The Diagnostics > Video > Cameras settings display only when the HDX
system detects a Polycom EagleEye Director.
Diagnostic Screen Description
Video Diagnostics Tests the color settings of your monitor for optimum picture
quality.
If the color bars generated during the test are not clear, or
the colors do not look correct, the monitor needs to be
adjusted.
Note: For HDX systems using a Polycom EagleEye
Director, this test is under Diagnostics > Video >
Monitor.
Diagnostic Screen Description
Camera Audio Meter Verifies microphone functionality. To use this feature,
speak aloud and verify that you can see dynamic signal
indications for two vertical microphones and five horizontal
microphones. If no signal indication appears for a specific
microphone, manually power off the EagleEye Director
and then power it back on.
Also verifies the reference audio signal: Set up a video
call. Let the far side speak aloud and verify that you can
see dynamic signal indications for the two reference audio
meters. If no signal indication appears for a specific
microphone, make sure the reference cable is connected
firmly.
After you verify microphone functionality, calibrate the
camera again.
Polycom EagleEye
Director > Camera
Video Diagnostics
Left Camera shows video from the left camera.
Right Camera shows video from the right camera.
Color Bars displays the color bar test screen.
