Polycom HDX 9004, HDX 9002, HDX 9001 Systems
The following table shows how you can connect video sources to a Polycom
HDX 9004, Polycom HDX 9002, or Polycom HDX 9001 system.
Video
Input
Number
Connector
Acceptable
Input
Resolution/
Frame Rate (fps)
Audio
Association
Power Control
1 HDCI Composite,
S-Video
People Only:
480i/60, 576i/50
None Provided
for
Polycom
EagleEye
HD
PTZ
Camera,
IR Input
Component People Only:
720p/60, 720p/50, 480p/60,
480p/30, 576p/50, 576p/25,
480i/60, 576i/50
1080p/30, 1080i/60,
1080p/25, 1080i/50
None Provided
for
Polycom
EagleEye
HD
cameras
PTZ
Camera,
IR Input
DVI-D People Only:
720p/30, 1080p/15
None Provided
for
Polycom
EagleEye
HD
PTZ
Camera,
IR Input
2 HDCI Composite,
S-Video
People or Content:
480i/60, 576i/50
None None PTZ
Camera
Component People or Content:
720p/60, 720p/50, 480p/60,
480p/30, 576p/50, 576p/25,
480i/60, 576i/50
People Only:
1080p/30, 1080i/60,
1080p/25, 1080i/50
None None PTZ
Camera
