Polycom realpresence group series Reference Guide

System Commands
Polycom, Inc. 177
configlayout
Gets or sets the Self View (PIP) location.
Syntax
configlayout monitor1 <get|list>
configlayout monitor1
<pip_lower_left|pip_lower_right|pip_upper_left|pip_top|pip_right|pip_bottom
|side_by_side|full_screen>
Parameter Description
User
Accessible Additional Restrictions
get Turns on the test tone. ✓
monitor1 You cannot specify a monitor in release 4.2.
This parameter is required, but ignored.
✓
list Lists the available Self View location
choices.
✓
pip_lower_left
Sets the Self View (PIP) to appear in the
lower left of the monitor.
✓
pip_lower_right
Sets the Self View (PIP) to appear in the
lower right of the monitor.
✓
pip_upper_left
Sets the Self View (PIP) to appear in the
upper left of the monitor
✓
pip_upper_right
Sets the Self View (PIP) to appear in the
upper right of the monitor.
✓
pip_top
Sets the Self View (PIP) to appear at the
top of the monitor.
✓
pip_right
Sets the Self View (PIP) to appear on the
right of the monitor.
✓
pip_bottom
Sets the Self View (PIP) to appear at the
bottom of the monitor.
✓
side_by_side
Sets the Self View (PIP) to appear next to
far site or content.
✓
full_screen
Sets the Self View (PIP) to appear full
screen.
✓

Polycom realpresence group series Specifications

General

Video Standards	H.264, H.263, H.264 High Profile
Audio Standards	G.711, G.728
Content Sharing	People+Content
Network	H.323, SIP
Security	AES encryption
Video Input	HDMI
Video Output	HDMI
Audio Input	HDMI
Audio Output	HDMI
Audio Features	Noise Reduction, Automatic Gain Control
Connectivity	Ethernet
Ports	Ethernet, HDMI
Compatibility	Microsoft Lync / Skype for Business, BlueJeans, Zoom
