R&S SMB100A User Manual

Instrument Function
R&S
®
SMB100A
92Operating Manual 1407.0806.32 ─ 21
The "Setup" menu provides access to basic instrument settings, regardless of the cur-
rently set operating mode or measurement. It contains information on the insstrument's
equipment, and comprises all settings for the general configuration of the instrument
and its interfaces.
To access the "Setup" menu, press the SETUP key.
The "Setup" menu is divided into functional sections as follows:
●
"System": covers general instrument parameters.
●
"Test": used to perform function tests.
●
"Environment": used to configure the controller interfaces.
●
"Remote": used to configure the remote control interfaces.
●
"Protection": used to set the protection level for service functions and security set-
tings.
●
"Settings": used to save or recall instrument settings or to preset the instrument to
factory settings.
Most submenus of this key can be accessed only via the SETUP key or the menu tree
( MENU key), with the following exceptions:
●
The "Reference Oscillator" dialog can also be accessed in the "RF" block and is
therefore described in the section on this block (see Chapter 5.3.4, "Reference
Oscillator", on page 141).
●
The "Save/Recall" dialog can also be accessed with the FILE key and is therefore
described in the section on this key (see Chapter 5.2.8, "Storing and Loading
Instrument Data - File Key", on page 126.
5.2.3.1 Internal Adjustments
The R&S SMB is extremely accurate due to the integrated adjustment procedures,
which you can execute directly on the instrument.
Self-calibration routines that do require additional (external) measurement equipment
are either described in the Service Manual of the instrument, or they require to be per-
formed by a Rohde & Schwarz service center.
Risk of invalid adjustment
In order to achieve correct adjustment of the instrument, make sure that the instrument
is warm before performing adjustments. The warm-up time is 30 minutes.
When to perform adjustments?
It is recommended to perform internal adjustments prior to any application that requires
a maximum of level and frequency accuracy, especially when a long period of time has
passed or if the ambient temperature of the instrument significantly differs from the one
of the last adjustment.
General Instrument Settings
