R&S SMB100A User Manual

Manual Operation
R&S
®
SMB100A
86Operating Manual 1407.0806.32 ─ 21
Table 4-1: List of the automatically assigned file extensions in the instrument
Function List type Contents File suffix
Instrument State Settings Instrument settings
*.savrcltxt
"User Correction" List User-defined level correction values
*.uco
Export Data *.txt or *.csv
"List Mode" List User-defined frequency/level value pairs
*.lsw
Export Data *.txt or *.csv
"Pulse Train List" User-defined offtime/ontime/repetition values
*.pulstrn
SMZ Settings Settings Data (firmware) of a connected SMZ frequency
multiplier
*.efmfirm
NRP Settings Settings NRP Settings
*.nrp
4.8 Legend of Front-Panel Controls
The following table lists all key functions available on the front panel. Key combinations
used on the PC keyboard to trigger key functions on the instrument front panel are also
described. Keyboard labels are described in alphabetical order.
In addition, a front panel key emulation and an on-screen keyboard can be used for
manual operation by mouse only.
Table 4-2: Cross-reference between the front panel keys and keyboard shortcuts
Front-panel key Key of PC keyboard Function
Turning the rotary
knob
Tab key (towards the right)
Shift + Tab (towards the left)
Sets the cursor with the rotary knob.
Pressing the rotary
knob
Enter Pressing the rotary knob confirms an entry; it has
the same function as the ENTER key.
Arrow keys Arrow keys Moves the cursor.
ENTER / *1 / dB(m) Enter
ALT + F12
Terminates an entry.
Confirms entries in the base unit and values with-
out a unit.
Selects dBm for the RF level and dB for level offset
and level step width.
. / *...# . / *...# Enters a period/decimal point. Enters a special
character.
- / A<->a - / (shift+) a—z Enters the sign.
Switches between upper-case and lower-case let-
ters.
0-9 / a...z CTRL+ 0-9 / a...z CTRL Enters the number/letter.
Legend of Front-Panel Controls
