Instrument Function
R&S
®
SMB100A
107Operating Manual 1407.0806.32 ─ 21
The DNS system uses the suffix for registration and name resolution to uniquely iden-
tify the instrument in the entire network.
To assign the DNS suffix manually, select Address Mode "Static".
Remote command:
:SYSTem:COMMunicate:NETWork[:COMMon]:DOMain on page 438
DNS Server
Determines the preferred server for name resolution. The DNS server contains the
underlying numerical values that are required for name resolution of the host name as
part of the IP address.
To select the DNS server manually, select Address Mode "Static".
Remote command:
:SYSTem:COMMunicate:NETWork[:IPADdress]:DNS on page 439
MAC Address
Indicates the MAC (Media Access Control) address, a unique identifier of the network
adapter in the R&S SMB.
Remote command:
:SYSTem:COMMunicate:NETWork:MACaddress on page 440
Restart Network
Terminates the network connection to the instrument and subsequently re-establishes
it.
Used this function to resolve network problems.
Note: Only the connection of the instrument to the network restarts, the network itself
is not affected.
Remote command:
:SYSTem:COMMunicate:NETWork:RESTart on page 440
5.2.3.13 Display/Keyboard Settings
In the "Display/Keyboard Settings" dialog the power-save mode and external keyboard
settings are made. It is opened using the SETUP or MENU key under "Environment".
General Instrument Settings
