Remote Control Commands
R&S
®
SMB100A
315Operating Manual 1407.0806.32 ─ 21
Parameters:
<State> 0 | 1 | OFF | ON
*RST: 0
Example:
OUTP OFF
deactivates the RF output.
Manual operation: See "RF On" on page 135
:OUTPut<hw>[:STATe]:PON <Pon>
Selects the state of the RF output when the instrument is switched on.
Parameters:
<Pon> OFF | UNCHanged
OFF
deactivates the output when the instrument is switched on (RF
OFF).
UNCHanged
restores the initial state of the RF output before the last turn off.
sets the output status as it was when the instrument was
switched off.
*RST: UNCHanged
Example:
OUTP:PON OFF
RF output A is deactivated when the instrument is switched on.
Manual operation: See "Power-On State - RF Signal" on page 151
7.12 SENSe, READ and INITiate Subsystems
The SENSe subsystem contains the commands for configuring the power measure-
ments with R&S NRP-Zxx power sensor(s) connected to the generator. The measure-
ment is started and the measurement result retrieved with the READ command. The
description of this commands is included in the following.
Up to four sensors can be connected to the signal generator. They are distinguished by
means of the suffix under SENSe, that means SENSe [1] ... SENSe 4.
:SENSe<ch>[:POWer]:APERture:DEFault:STATe............................................................. 316
:SENSe<ch>[:POWer]:APERture:TIMe.............................................................................316
:INITiate<ch>[:POWer]:CONTinuous................................................................................316
:READ<ch>[:POWer]?.................................................................................................... 317
:SENSe<ch>[:POWer]:CORRection:SPDevice:STATe....................................................... 317
:SENSe<ch>[:POWer]:DISPlay:PERManent:STATe.......................................................... 318
:SENSe<ch>[:POWer]:DISPlay:PERManent:PRIority.........................................................318
:SENSe<ch>[:POWer]:FILTer:LENGth:AUTO?..................................................................318
:SENSe<ch>[:POWer]:FILTer:LENGth[:USER]..................................................................319
:SENSe<ch>[:POWer]:FILTer:NSRatio.............................................................................319
:SENSe<ch>[:POWer]:FILTer:NSRatio:MTIMe..................................................................320
SENSe, READ and INITiate Subsystems
