R&S SMB100A User Manual

Remote Control Commands
R&S
®
SMB100A
312Operating Manual 1407.0806.32 ─ 21
:OUTPut<hw>:AFIXed:RANGe:LOWer?
Queries the minimum level which can be set when the attenuator is fixed, see :
OUTPut<hw>:AMODe.
Return values:
<Lower> float
Increment: 0.01
Example:
OUTP:AFIX:RANG:LOW?
queries the minimum level for the FIXed setting.
Example:
Response: -50
The minimum level is -50 dBm.
Usage: Query only
Manual operation: See "Fixed Range (PEP) In" on page 149
:OUTPut<hw>:AFIXed:RANGe:UPPer?
Queries the maximum level which can be set when the attenuator is fixed, see :
OUTPut<hw>:AMODe.
Return values:
<Upper> float
Increment: 0.01
Example:
OUTP:AFIX:RANG:UPP?
queries the maximum level for the FIXed setting for the RF out-
put.
Example:
Response: -27
The maximum level is -27 dBm.
Usage: Query only
Manual operation: See "Fixed Range (PEP) In" on page 149
:OUTPut<hw>:ALC:SEARch:MODE <Mode>
Activates/deactivates the RF output during the power search.
Parameters:
<Mode> NORMal | MINimum
*RST: NORMal
Example:
POW:ALC:SEAR:MODE NORM
during the power search, the RF output is active.
Manual operation: See "RF During Power Search - ALC" on page 153
OUTPut Subsystem
