R&S SMB100A User Manual

Remote Control Commands
R&S
®
SMB100A
308Operating Manual 1407.0806.32 ─ 21
Parameters:
<BinaryBlock> #<number><length_entry><data>
#: Hash sign; always comes first in the binary block
<number>: the first digit indicates how many digits the subse-
quent length entry has
<length_entry>: indicates the number of subsequent bytes
<data>: binary block data for the specified length.
For files with a size with more than nine digits (gigabytes), the
instrument allows the syntax #(<Length>), where <Length>
is the file size in decimal format.
Parameters for setting and query:
<Filename> string
String parameter to specify the name of the file.
Example:
MMEMory:DATA '/var/user/test.txt',#15hallo
Writes the block data to the file test.txt.
The digit 1 indicates a length entry of one digit; the digit 5 indi-
cate a length of the binary data (hallo) in bytes.
MMEMory:DATA? '/var/user/test.txt'
Sends the data of the file test.txt from the instrument to the
controller in the form of a binary block.
Response: #15hallo
Usage: SCPI confirmed
:MMEMory:DCATalog? <path>
Returns the subdirectories of a particular directory.
Query parameters:
<path> String parameter to specify the directory. If the directory is omit-
ted, the command queries the content of the current directory,
queried with :MMEMory:CDIRectory command.
Return values:
<Catalog> <file_entry>
Names of the subdirectories separated by colons. The first two
strings are related to the parent directory.
Example: See "Working with Files and Directories" on page 304.
Usage: Query only
:MMEMory:DCATalog:LENGth? [<Path>]
Returns the number of subdirectories in the current or specified directory.
Query parameters:
<Path> String parameter to specify the directory. If the directory is omit-
ted, the command queries the contents of the current directory,
to be queried with :MMEMory:CDIRectory command.
MMEMory Subsystem
