Remote Control Commands
R&S
®
SMB100A
347Operating Manual 1407.0806.32 ─ 21
Note: This value also applies to the step width of the rotary knob of the instrument and
increases or decreases the frequency accordingly, when you work in user-defined step
mode.
Parameters:
<Increment> float
Range: full frequency range
Increment: see the data sheet: RF characteristics > Resolution
of setting
*RST: 1E6
Example:
FREQ:STEP 50 kHz
sets the step width for the frequency setting to 50 kHz.
Manual operation: See "Variation Step" on page 140
[:SOURce<hw>]:FREQuency:STEP:MODE
<Mode>
Activates (USER) or deactivates (DECimal) the user-defined step width used when
varying the frequency value with the frequency values UP/DOWN. The command is
linked to the command "Variation Active" for manual control, i.e. the command also
activates/deactivates the user-defined step width used when varying the frequency
value with the rotary knob.
Parameters:
<Mode> DECimal | USER
*RST: DECimal
Example:
FREQ:STEP 50 kHz
sets the step width for the frequency setting to 50 kHz.
FREQ:STEP:MODE USER
actives this step width for frequency variation with the rotary
knob (manual control) and with frequency values UP/DOWN
(remote control).
Manual operation: See "Variation Active" on page 140
7.13.5 SOURce:INPut Subsystem
The SOURce:INPut subsystem contains the commands for configuring the inputs for
external modulation signals. The instrument trigger setting influences all sweeps and is
effective in the List mode (Instrument Trigger).
[:SOURce<hw>]:INPut:MODext:IMPedance......................................................................347
[:SOURce<hw>]:INPut:MODext:WIGNore.........................................................................348
[:SOURce]:INPut:TRIGger:SLOPe................................................................................... 348
[:SOURce<hw>]:INPut:MODext:IMPedance <Impedance>
Sets the impedance for an externally applied modulation signal.
SOURce Subsystem
