Instrument Function
R&S
®
SMB100A
120Operating Manual 1407.0806.32 ─ 21
Via remote control, there is no password required.
Remote command:
:SYSTem:ULOCk on page 437
:SYSTem:DLOCk on page 436
:SYSTem:KLOCk on page 436
Security Password
Enters the password that is required to enable or to disable the settings protected by a
security password. Default is '123456'.
Note: It is highly recommended that you to change the default security password
before connecting the instrument to the network.
All settings are only accepted after the "Accept" button is pressed.
Accept
Applies the modified settings, provided the security password is entered correctly.
Note: This action can not be undone. Keep in mind, that a changed password is never
reset, even if you perform a factory preset.
Bluetooth Pin
Sets the Bluetooth pin of an external Bluetooth device. The pin is required to enable
remote control via an external Bluetooth device.
Requires a Bluetooth adapter (recommended extra, see data sheet) .
5.2.3.19 Save/Recall
The "Save/Recall" submenu can also be called up with the FILE key and is therefore
described in the section of this key (see Chapter 5.2.8, "Storing and Loading Instru-
ment Data - File Key", on page 126).
5.2.3.20 Factory Preset
The "Factory Preset" dialog provides a function to reset the instrument's settings to
their factory state. This function is activated by pressing the "Execute Factory Preset"
button.
Factory Preset
Reset the instrument's settings to their factory state.
Note: "Factory Preset" resets the "Remote Channel" and network settings to the
default values.
Executing "Factory Preset" via remote control terminates the connection to the instru-
ment, if these settings had been configured to values different to the default ones.
General Instrument Settings
