[:SOURce<hw>]:SWEep[:FREQuency]:EXECute
Starts an RF frequency sweep cycle manually.
The command is only effective in single mode.
Example:
TRIG:FSW:SOUR SING
SOUR:SWE:FREQ:MODE AUT
SWE:FREQ:EXEC
triggers a frequency sweep at the RF output.
Usage: Event
Manual operation: See "Execute Single Sweep - Frequency Sweep" on page 178
[:SOURce<hw>]:SWEep[:FREQuency]:LFConnector <LfConnector>
Activates the output of a sweep voltage ramp at the LF connector.
The voltage range is set with commands
SOURce:SWEep:FREQuency:OVOLtage:STARt and …:STOP
Parameters:
<LfConnector> 0 | 1 | OFF | ON
*RST: 0
Example:
SWE:LFC ON
activates the output of a linear voltage ramp from sweep start to
sweep stop at the LF connector.
SWE:OVOL:STAR 0V
SWE:OVOL:STOP 3V
'the voltage at sweep start is 0 Volt and at sweep stop 3 V.
Manual operation: See "Use LF connector to output sweep voltage - RF Frequency
Sweep" on page 181
[:SOURce<hw>]:SWEep[:FREQuency]:MODE <Mode>
Sets the sweep mode.
The keyword [:FREQuency] can be omitted (see example). The command is then
SCPI-compliant.
