Remote Control Commands
R&S
®
SMB100A
301Operating Manual 1407.0806.32 ─ 21
Manual operation: See "File Options" on page 123
:HCOPy:FILE[:NAME]:AUTO:STATe <State>
Activates/deactivates automatic naming of the hardcopy files.
Parameters:
<State> 0 | 1 | OFF | ON
*RST: 1
Example:
HCOP:FILE:AUTO:STAT OFF
Deactivates automatic naming.
Manual operation: See "Automatic Naming" on page 123
:HCOPy:IMAGe:FORMat <Format>
This command selects the bitmap graphic format for the screenshot. You can also
retrieve the data using command HCOP:DATA?.
This command is an alias to command HCOPy:DEVice:LANGuage.
Parameters:
<Format> BMP | JPG | XPM | PNG
*RST: PNG
Example:
HCOP:IMAG:FORM XPM
Selects the image format XPM.
Manual operation: See "File Options" on page 123
:HCOPy:IMAGe:SIZE <Size>
Selects the image size of the hardcopy. The first value of the size setting defines the
width, the second value the height of the image.
Parameters:
<Size> string
*RST: depends on device
Example:
HCOP:IMAG:SIZE 640,480
Sets width and height of the image.
7.9 KBOard Subsystem
The KBOard system contains the commands to set the external keyboard.
:KBOard:LANGuage.......................................................................................................302
:KBOard:LAYout............................................................................................................ 302
KBOard Subsystem
