Remote Control Commands
R&S
®
SMB100A
456Operating Manual 1407.0806.32 ─ 21
Example:
UNIT:ANGL DEG
sets DEG as a default unit for all commands which determine
angle values.
:UNIT:POWer <Power>
Defines the default unit for power parameters. This setting affects the GUI, as well as
all remote control commands that determine power values.
Parameters:
<Power> V | DBUV | DBM
*RST: DBM
Example:
UNIT:POW V
sets V as a default unit for all commands which determine power
values.
7.19 Direct Commands for the Stereo/RDS Coder Option
R&S SMB-B5
The direct command allow to access all functions of the stereo coder option.
Some of the functions are also available via SCPI commands. In this case, it is recom-
mended to use the SCPI commands in order to keep the settings of the R&S SMB and
the stereo coder synchronized. Direct command for which a SCPI command is availa-
ble are marked with “for documentation reasons only” and the SCPI command is given.
The direct commands are sent to the Stereo/RDS Coder with
[SOURce:]STEReo:DIRect "command string".
Information is queried with STEReo:DIRect? "command string".
All parameters are string parameters, this is the reason why all of them have to be sent
in qotation marks ( " – characters are part of the full direct command ! ).
Prior to using the stereo coder, the stereo modulation of the R&S SMB has to be
switched on with command SOURce:STEReo:STATe ON. The SCPI command
SOURce:STEReo:AUDio:FREQuency sets the LF-Generator frequency and com-
mand SOURce:STEReo:MMF limits the modulation frequency. These commands have
no counterpart in the direct commands.
7.19.1 Remote-Control Commands
STEReo:DIRect "<FFG>=<RetrNumb>,<DataSeq#1>,<DataSeq#2>,..."
STEReo:DIRect? "<FFG>"
Transmits data via free format groups (FFGs). A free format group can be filled with
any desired data. (5 bits in block B and 16 bits each in blocks C and D of the group).
Direct Commands for the Stereo/RDS Coder Option R&S SMB-B5
