R&S SMB100A User Manual

Remote Control Commands
R&S
®
SMB100A
449Operating Manual 1407.0806.32 ─ 21
Return values:
<Result> 0 | 1 | RUNning | STOPped
0
Success
1
Fail
*RST: STOPped
Example:
TEST:ALL:STAR
Starts the self-test
TEST:ALL:RES?
Usage: Query only
Manual operation: See "Start Selftest" on page 101
:TEST<hw>:DIRect
<HW_assembly>,<subadress>,<hex data string>
:TEST<hw>:DIRect? <HW_assembly>,<subadress>
The respective hardware assembly responds directly to the command; any safety
mechanisms are bypassed. This function is only available via remote control.
Example:
TEST:DIR 'SSYN',0,#H12345678
TEST:DIR? 'SSYN',0
Response: #H12345678
7.17 TRIGger Subsystem
The TRIGger system contains the commands for selecting the trigger source for the
RF and LF sweep. The trigger input connectors are configured in the SOURce:INPut
subsystem.
The trigger system of the R&S SMB is a simplified implementation of the SCPI trigger
system. The TRIGger system differs from the SCPI system as follows:
●
No INITiate command; the instrument behaves as if INITiate:CONTinuous
ON were set.
●
Under TRIGger several sweep subsystems exist.
Other commands associated with the trigger system of the R&S SMB can be found in
the modulation and RF signal subsystems.
TRIGger<hw>
●
Suffix TRIGger<1|2> is not permitted
●
TRIGger0 activates the LF output.
TRIGger Subsystem
