Manual Operation
R&S
®
SMB100A
81Operating Manual 1407.0806.32 ─ 21
Creating a new list mode data list
A new list can be created under a new name either by generating a blank file in the
"File Select" menu (see section Chapter 4.7, "File Management", on page 82) or by
changing an existing list which will then be saved under a new name.
1. To create an empty data list, select "RF > List Mode > List Mode Data... > New
List" or respectively "RF > User Correction > User Cor. Data... > New User Correc-
tion Data" and enter the file name of the new data list.
2. To open the data list for editing, select the associated button "Edit User Correction
Data..." or "Edit List Mode Data..." in the individual menu.
Edit the list and save it under a new name.
4.6 How to Use the Help System
The R&S SMB is equipped with a context-sensitive help function. A help page is avail-
able for each parameter and can be called any time during instrument operation.
Calling context-sensitive and general help
► To display the general help dialog box, press the HELP (F1) key.
The help dialog is displayed. A topic containing information about the current menu
or the currently opened dialog box and its function is displayed.
On top, the help dialog box contains a navigation bar with:
●
"Contents" - accesses a table of help contents
●
"Index" - switches to an index table
●
"Back "/"Previous"/"Next" for navigation to further help topics
Navigating in the table of contents
1. To navigate within the table of contents entries, use the UP/DOWN keys. Entries
that contain further entries are marked with a plus sign.
2. To display a help topic, press the "ENTER" key.
The corresponding help topic is displayed.
How to Use the Help System
