Instrument Function
R&S
®
SMB100A
113Operating Manual 1407.0806.32 ─ 21
Parameter
Hostname
Instrument-specific host name
Description RF and microwave signal generator
Negotiation Auto Detect
VXI-11 Discovery Enabled
The LAN settings are configured using the instrument's LXI Browser Interface descri-
bed in Chapter 2.8, "LXI Configuration", on page 45.
To open the "Instrument Home Page" (welcome page), type the instrument's computer
name (host name) or IP address in the address field of the browser on your PC, for
example http://10.111.10.175.
Note: Do not add the missing zeros in the IP address, while opening the Instrument
Home Page.
Remote command:
n.a.
5.2.3.17 Protection
This "Protection" dialog provides access to the unlocking of different protection levels .
Access:
► Select "Setup > Protection"
After power on the instrument, all protection levels are locked. To unlock the protec-
tion, the correct password must be entered, see "To unlock or lock a protection level..."
on page 114.
The following functions are protected in the respective levels:
●
Protection Level 1
Protects against accidental changes to certain settings, e.g. clock and date, net-
work settings or instrument names. You can access this protection level with the
password 123456.
●
Protection Level 2
Provides access to the unlocking of protected service functions. It is accessible for
authorized personnel of Rohde & Schwarz service departments.
●
Protection Level 3-5
Are reserved for factory internal use.
General Instrument Settings
