R&S SMB100A User Manual

Remote Control Commands
R&S
®
SMB100A
313Operating Manual 1407.0806.32 ─ 21
:OUTPut<hw>:AMODe <AMode>
Selects the mode of the attenuator at the RF output (Attenuator MODe).
Parameters:
<AMode> AUTO | FIXed
AUTO
The attenuator is switched automatically. The level settings are
made in the full range.
FIXed
The level settings are made without switching the attenuator.
When this operating mode is switched on, the attenuator is fixed
in its current position and the resulting variation range is defined.
*RST: AUTO
Example:
POW:ALC ON
activates automatic level control for RF output.
OUTP:AMOD FIX
sets the fixed mode with uninterrupted level for RF output.
Manual operation: See "Attenuator Mode" on page 149
:OUTPut<hw>:FILTer:AUTO <Auto>
Activates automatic switching of the low harmonic filter.
Parameters:
<Auto> 0 | 1 | ON | OFF
*RST: 0
Example:
OUTP:FILT:AUTO 1
Activates the auto mode.
Manual operation: See "Mode" on page 149
:OUTPut<hw>:FILTer[:LPASs]:STATe <State>
Switches the filter state in manual mode and disables the automatic mode, if activated.
Parameters:
<State> 0 | 1 | OFF | ON
*RST: 0
Example:
OUTP:FILT:AUTO 0
OUTP:FILT:LPAS:STAT 1
Selects manual mode and activates the low harmonic filter.
OUTP:FILT:STAT?
Queries the current filter activity.
Manual operation: See "State" on page 149
OUTPut Subsystem
