R&S SMB100A User Manual

Remote Control Commands
R&S
®
SMB100A
455Operating Manual 1407.0806.32 ─ 21
Manual operation: See "Mode" on page 221
:TRIGger<hw>[:SWEep][:IMMediate]
Starts all sweeps which are activated for the respective path. The command starts all
sweeps which are activated.
The sweep to be executed depends on the respective MODE setting
(:SOUR:SWEep:POW|FREQ:MODE and :SOUR:LFO:SWEep[:FREQ]:MODE).
The command corresponds to the manual-control command "Execute Trigger".
Example:
TRIG
starts all active sweeps.
Usage: Event
Manual operation: See "Execute Single Sweep - Frequency Sweep" on page 178
:TRIGger<hw>[:IMMediate]
The command immediately starts the activated sweep.
The command performs a single sweep and therefore applies to sweep mode AUTO
with sweep source SINGle. Use the commands
TRIG:FSW|LFFS|PSW|[:SWE]:SOUR SING, and SOUR:SWE:FREQ|POW:MODE, or
SOUR:LFO:SWE:[FREQ:]MODE to set the respective sinlge sweep. You can alterna-
tively use an IMMediate command instead of the respective SWEep:
[FREQ:]|POW:EXECute command.
Example:
TRIG
starts all active sweeps.
Usage: Event
Manual operation: See "Execute Single Sweep" on page 223
7.18 UNIT Subsystem
The UNIT subsystem contains the commands specifying which units are valid if no unit
is indicated in a command. These settings are valid for the entire instrument.
:UNIT:ANGLe <Angle>
Defines the default unit for the phase modulation angle. It is not valid for commands
which determine angle values, e.g. RF phase. It does not influence the manual control
parameter unit and the display.
Parameters:
<Angle> DEGRee | RADian
*RST: RADian
UNIT Subsystem
