Remote Control Commands
R&S
®
SMB100A
376Operating Manual 1407.0806.32 ─ 21
Parameters:
<Source> INTernal | EXTernal | INT,EXT
INTernal
Uses the internally generated signal for modulation. To configure
the LF signal, use the commands of the SOURce:LFOutput Sub-
system subsystem.
EXTernal
Uses an externally applied modulation signal.
INT,EXT
Uses both, the internal and external modulation signals.
*RST: INT
Example:
PM:SOUR INT
selects the internal modulation source.
Manual operation: See "ɸM Source" on page 207
[:SOURce<hw>]:PM:STATe
<State>
Activates phase modulation.
Note: Activation of PM deactivates frequency modulation (FM).
Parameters:
<State> 0 | 1 | OFF | ON
*RST: 0
Example:
PM:STAT ON
activates PM.
Manual operation: See "State" on page 207
7.13.12 SOURce:POWer Subsystem
This subsystem contains the commands for setting the output level, level control and
level correction of the RF signal.
Other units can also be used instead of dBm:
●
by entering the unit directly after the numerical value (example :POW 0.5V)
●
by changing the DEFault unit in the UNIT system (see the command :UNIT:
POWer).
[:SOURce<hw>]:POWer:ALC:OMODe............................................................................. 377
[:SOURce<hw>]:POWer:ALC:SONCe.............................................................................. 377
[:SOURce<hw>]:POWer:ALC[:STATe]............................................................................. 377
[:SOURce<hw>]:POWer:ATTenuation:RFOFf:MODE.........................................................378
[:SOURce<hw>]:POWer:EMF:STATe...............................................................................378
[:SOURce<hw>]:POWer[:LEVel][:IMMediate][:AMPLitude]..................................................379
[:SOURce<hw>]:POWer[:LEVel][:IMMediate]:OFFSet........................................................379
[:SOURce<hw>]:POWer[:LEVel][:IMMediate]:RCL.............................................................380
[:SOURce<hw>]:POWer:LIMit[:AMPLitude].......................................................................380
SOURce Subsystem
